Πεδιόμετρο Anga DVB- S2 + T2 + C Meter SF-8000C

 Πεδιόμετρο Anga DVB- S2 + T2 + C Meter

System Resources
Main Processor: 600M Hz based CPU
Flash Memory: 64M Bits
DDR SDRAM: 1024M Bits
Tuner/Front-end
Tuner Type: DVB-S/DVB-S2
Input Connector: F-type,Connector,Male
Frequency Range: 950MHz~2150MHz
Signal Level: -65~-25dBm
Impedance: 75Ω
LNB Power & Polarization:
Vertical:+13V
Horizontal:+18V
Current:Max.500mA
Overload Protection
DiSEqC Control: Version 1.0/1.1/1.2/1.3,USALS Available
22KHz Tone: Frequency:22±1KHz
Demodulation: QPSK,8PSK,16APSK,32APSK
Symbol Rate: 2~45Msps
Tuner Type
DVB-T/DVB-T2，DVB-C
Input Connector: IEC-type,Connector,Male
Input Frequency: (UHF)470-866MHz,(VHF)170-230MHz
Signal Level: -82~-20dBm
Impedance: 75Ω
ANT Voltage Output: 5V 12V 24V
Demodulation: QPSK,16-QAM, 64-QAM, 256-QAM
Bandwidth: 6,7,8 MHz
Power Supply
Input Voltage Adapter: Free Voltage (100~240V  AC  50/60Hz)
Power Consumption: 11W MAX
Power Charger Output: 14V DC 3.0A
Battery: 12.6V/4000mAh
Battery Charging Time: 3~6H
Battery Standard Discharging Time: >5H
A/V Data input/output
CCTV Input Type: CVBS
Video Output: CVBS (PAL&NTSC)
Audio: Audio L/R input/output
Speaker: Built-in 8Ω 1W speaker
HD TV  OUT: VER1.4 interface,up to 1080p
HD TV  IN: VER1.4 interface,up to 1080p
USB: 1*USB 2.0 slot Compatible for Host
Transport Stream: MPEG-2/4,H.264/ H.265
Physical Specification
LCD Display: 5 inch
Size[W*H*D]: 210 x150x 52(mm)
Net Weight: 0.93Kg
Operating Temperature: 0℃ ~ + 45℃
Storage Temperature: -10℃ ~ + 70℃
Storage Humidity: 5%~95% RH (Non-Condensing)
