Κάμερα BULLET IP 4MP 2.8mm Up to 30m ΜΕ POE IR range IP67 HIKVISION/HiWatch HWI-B140H

Κάμερα BULLET IP 4 MP 2.8mm Up to 30m ΜΕ POE IR range IP67 HIKVISION/HiWatch

• Κάμερα Bullet,IP,της σειράς HiWatch,κατασκευασμένη απο την HIKVISION.
• Aνάλυση 4 MP,σταθερός φακός 2.8mm,κωδικοποίηση βίντεο H.265 / H.264.
• Nυχτερινή λήψη (ΙR LED εώς 30 μέτρα) και ανίχνευση κίνησης.
• Προστασία απο σκόνη και νερό (IP 67),τροφοδοσία POE (12 VDC/0.4 A)
• H συσκευασία περιλαμβάνει Bullet κάμερα,βίδες,ούπα και εγχειρίδιο χρήσης.

Τεχνικά χαρακτηριστικά:

Camera:
HWI-B140H
Appearance:
Bullet
Image Sensor:
1/3″ Progressive Scan CMOS
Minimum Illumination:
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed:
1/3 s ~ 1/100, 000 s
Slow Shutter:
Yes
Auto-Iris:
No
Day & Night:
IR Cut Filter
Digital Noise Reduction:
3D DNR
WDR:
120 dB
Angle Adjustment:
Pan: 0° ~ 360°, Tilt: 0° ~ 180°, Rotation: 0° ~ 360°
Focal Length:
2.8 mm, 4 mm
Aperture:
F2.0
Focus:
Fixed
Angle of View:
•2.8 mm, Horizontal FOV 100°, Vertical FOV 55°, Diagonal FOV 117°

•4 mm, Horizontal FOV 77°, Vertical FOV 42°, Diagonal FOV 88°
Lens Mount:
M12
IR Range:
Up to 30 m
Wave Length:
850 nm
Video Compression:
•Main Stream: H.265/H.264

•Sub Stream: H.265/H.264/MJPEG
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.264+:
Main Stream Supports
H.265 Type:
Main Profile
H.265+:
Main Stream Supports
Video Bit Rate:
32 Kbps to 8 Mbps
Region of Interest:
1 Fixed Region for Main Stream and Sub-Stream
Resolution:
4MP
Main Stream Max. Frame Rate:
•50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)

•60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-Stream Max. Frame Rate:
•50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

•60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:
BLC, 3D DNR
Image Settings:
•Saturation, Brightness, Contrast, Sharpness, AGC

•White Balance Adjustable by Client Software or Web Browser
Day/Night Switch:
Auto, Scheduled, Day, Night
Alarm Trigger:
Motion Detection, Video Tampering Alarm, Illegal Login
Network Storage:
NAS (NFS, SMB/CIFS)
Protocols:
•TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,RTCP

•PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour
General Function:
•Anti-Flicker, Heartbeat, Mirror, Password Protection

•Privacy Mask, Watermark, IP Address Filter
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View:
Up to 6 Channels
User/Host:
Up to 32 Users, 3 Levels: Administrator, Operator and User
Client:
iVMS-4200, Hik-Connect
Web Browser:
IE8+, Chrome 31.0-44, Firefox 30.0-51
Communication Interface:
1 RJ45 10M/100M Self-Adaptive Ethernet Port
Operating Conditions:
-30 °C ~ 50 °C
Operating Humidity:
95% or Less (Non-Condensing)
Power Supply:
12 VDC ± 25%, 5.5 mm Coaxial Power Plug, PoE (802.3af, Class 3)
Power Consumption:
12 VDC, 0.4 A, Max: 5 W, PoE: (802.3af, 36 V to 57 V), 0.2 A ~ 0.1 A, Max: 6.5 W
Ingress Protection Level:
IP 67
Material:
Front Cover: Metal, Camera Body: Plastic, Bracket: Plastic
Dimensions:
Camera: Ø 70 mm × 191.3mm, With Package: 216 mm × 121 mm × 118 mm
Weight:
Camera: Approximately 280g,  With Package: Approximately: 530g
