Κεραία VHF Marine Cte Gp160- G156

Κεραια VHF Marine με ευρος συχνοτήτων 145…175 MHz.

MODEL GP 160 5/8
ANTENNA TYPE 5/8 λ ground-plane
FREQUENCY Tunable by cutting within: 145…175 MHz
IMPEDANCE Nom. 50 Ω
RADIATION Omnidirectional
POLARISATION Vertical
GAIN 5 dBi 3 dBd
BAND WIDTH 6 MHz (SWR ≤ 2.0)
SWR ≤ 1.2 @ f. res.
MAX. POWER 500 W
ANTISTATIC PROTECTION All metal parts DC-grounded
(Connector shows a DC-short)

MECHANICAL

TEMP. RANGE -30° C → +70° C
CONNECTOR UHF-female (fitting PL-259)
WIND SURFACE 0.028 m²
WIND LOAD 35 N @ 160 km/h
COLOUR White/bright chrome
MATERIALS Shroud : Polyurethane coated glass fibre
Metal parts: Bright chromed brass
TOTAL HEIGHT Approx. 1.34 m
DIA. IN TOP END 5 mm
DIA. IN BOTTOM END 8 mm
WEIGHT Approx. 1.3 kg
MOUNTING On 27 mm dia. mast tube (3/4” water pipe)
